AL1008 25–30 70.0 mm

AD4001 6–8* 55 mm
AD4002 8–10* 55 mm
AD4003 10–12.5 65 mm
AD4004 12.5–15 65 mm

AD4005 15–17.5 65 mm
AD4006 17.5–20 95 mm
AD4007 20–25 100 mm
AD4008 25–30 100 mm
AL1101 6–10 100 mm
AL1102 10–20 100 mm
AL1103 20–30 150 mm
SL1001 Set 0/1.2–60 mm 11 mm
SL1002 Set 0/1.2–30 mm 11 mm
SL1003 Set 30 – 60 mm 11 mm
Slotmaster Standard Anvil (mm)
Art. Nr.? Measuring range? ? – Anvil / Disc
SL1101 Pos. 11 1.2–30 mm 11 mm
SL1102 Pos. 21 30–60 mm 11 mm
SL1103 Pos. 22 30–60 mm 16 mm
SL1104 Pos. 31 60–90 mm 11 mm
SL1105 Pos. 32 60–90 mm 16 mm
SL1106 Pos. 41 90–120 mm 11 mm
SL1107 Pos. 42 90–120 mm 16 mm
SL1108 Pos. 51 120–150 mm 11 mm
SL1109 Pos. 52 120–150 mm 16 mm
Slotmaster Special–Accessories (mm)
Art. Nr.? Measuring range? ? – Anvil / Disc
SL2101 Pos. 12 0–30 mm with piston 30/9 mm, 30/30 mm
SL1202 Pos. 12 0–30 mm without piston 30 mm
SL1203 Pos. 13 1.0–30 mm 9 mm
SL1204 Pos. 14 2.0–30 mm 16 mm
SL1205 Pos. 23 30–60 mm 9 mm
SL1206 Pos. 24 30–60 mm 16 mm
SL1207 Pos. 11 0–30 mm only piston 11 mm
SL1208 Pos. 11 0–30 mm only Sleeve 11 mm
SL1209 Pos. 12 0–60 mm only piston 11 mm
SL1210 Pos. 12 0–60 mm only Sleeve 11 mm
SL1301 Multi–Gauge mm, (includes in Set)
SL1302 Dial Gauge Compact mm
Slotmaster Special-Accessories (Inch)
Art. Nr.? Measuring range ? – Anvil / Disc
SZ2202 Pos. 12 0–1 Inch without piston 30 mm
SZ2203 Pos. 13 0–1 Inch 9 mm
SZ2204 Pos. 14 0–1 Inch 16 mm
SZ2205 Pos. 23 1–2 Inch 9 mm
SZ2206 Pos. 24 1–2 Inch 16 mm
SZ2251 Pos. 11 0–1 Inch Piston only 11 mm

SZ2252 Pos. 11 0–1 Inch Sleeve only 11 mm
SZ2253 Pos. 12 1–2 Inch Piston only 11 mm
SZ2254 Pos. 12 1–2 Inch Sleeve only 11 mm
SZ2301 Multi-Gauge Inch, (includes in Set)
SZ2302 Dial Gauge Compact Inch
Slotmaster Standard Anvil (Inch)
Art. Nr.? Measuring range? ? – Anvil / Disc
SZ2101 0–1 Inch 11 mm
SZ2102 1–2 Inch 11 mm
SZ2103 1–2 Inch 16 mm
SZ2104 2–3 Inch 11 mm
SZ2105 3–4 Inch 16 mm
SZ2106 4–5 Inch 16 mm
SZ2107 5–6 Inch 16 mm
SZ2108 6–7 Inch 16 mm
Slotmaster imperial (Inch)
Art. Nr.? Measuring range? ? – Anvil / Disc
SZ2001 Set 0–2 Inch 11 mm
SZ2002 Set 0–1 Inch 11 mm
SZ2003 Set 1–2 Inch 11 mm
IE5101 Radio-Modul for IM50xx
IE5102 USB Receiver for IE 5101
IE5103 Interface Cable 2 m
IE5104 Measuring-PC 8.4 inch
IE5105 Measuring-PC 17 inch
IE5106 ComGage Compact Software
IE5107 ComGage Professional Software
VL3001 30–400 50 mm
VL3002 30–400 100 mm
VL3003 30–400 200 mm
VL3004 30–400 350 mm
VL3005 30–400 500 mm
VL3006 30–400 750 mm
VL3007 30–400 1000 mm
VL3008 30–400 1500 mm
VL3301 400–1150 500 mm
VL3302 400–1150 750 mm
VL3303 400–1150 1000 mm
Art. Nr. DeSCRJPTion Measuring range Measuring depth
SVL3101 Angle 90° for ? 30–400 mm 50 mm
Art. Nr.? DeSCRJPTion Measuring range ? in mm
VL3203 Tripod for 60–90 mm
VL3204 Tripod for 90–140 mm
VL3205 Tripod for 140–240 mm
VL3206 Tripod for 240–400 mm
VL3221 Tripod for 50–75 mm
VL3222 Tripod for 75–115 mm
VL3323 Tripod for 115–185 mm
VL3224 Tripod for 185–315 mm
ECO S3 ? 30–90 mm including:
3 MICROTEST ECO-Line-Internal-Micrometer ? 30–90 mm,
2 control rings ECO-Line ? 40/60 mm, 1 Display ECO-Line,
1 Extension 100 mm, 1 tool set.
ECO S4 ? 90–400 mm including:
3 MICROTEST ECO-Line-Internal-Micrometer ? 90–400 mm,
2 control rings ECO-Line ? 90/240 mm, 1 Display ECO-Line,
1 Extension 100 mm, 1 tool set.
ECO S5 ? 30–400 mm including:
6 MICROTEST ECO-Line-Internal-Micrometer ? 30–400 mm,
3 control rings ECO-Line ? 40/90/240 mm, 1 Display ECO-Line,
1 Extension 100 mm, 1 tool set.
ECO S7 ? 50–315 mm including:
4 MICROTEST ECO-Line-Internal-Micrometer ? 50–315 mm,
2 control rings ECO-Line ? 75/185 mm, 1 Display ECO-Line,
1 Extension 100 mm, 1 tool set.
IES001 ? 10–20 mm including:? 4 Cone-Internal-Micrometer ? 10–20 mm, 2
control rings ? 12.5/17.5 mm, 1 Extension 100 mm, 1 tool set.
IES002A ? 6–30 mm including: 8 Cone-Internal-Micrometer ? 6–30 mm*, 4
control rings ? 8/12.5/17.5/25 mm, 2 Extension 100 mm, 1 Extension
150 mm, 1 tool set.
IES002B ? 10–30 mm including: 6 Cone-Internal-Micrometer ? 10–30 mm, 3
control rings ? 12.5/17.5/25 mm, 1 Extension 100 mm, 1 Extension 150
mm, 1 tool set.
IES003 ? 30–90 mm including: 3 MICROTEST-Internal-Micrometer ? 30–90
mm, 2 control rings ? 40/90 mm, 1 Extension 200 mm, 1 screwdriver.
IES004 ? 90–400 mm including: 3 MICROTEST-Internal-Micrometer ? 90–400
mm, 2 control rings ? 90/240 mm, 1 Extension 200 mm, 1 tool set.
IES005 ? 30–400 mm including: 6 MICROTEST-Internal-Micrometer ? 30–400
mm, 3 control rings ? 40/90/240 mm, 1 Extension 200 mm, 2 tool sets.
IES006 ? 6–400 mm including: 8 Cone-Internal-Micrometer ? 6–30 mm*,
6 MICROTEST-Internal-Micrometer ? 30–400 mm, 4 control rings
? 8/12.5/17.5/25, 3 control rings ? 40/90/240 mm, 4 Extension
100/150/200 mm, 1 tool set.
IES007 ? 50–315 mm including: 4 MICROTEST-Internal-Micrometer ? 50–
315 mm, 2 control rings ? 75/185 mm, 1 Extension 200 mm, 1 tool set.
0,0001 mm
IG5002-G 3-Point MICROTEST 40–60 20 mm 110 mm ± 1.5 μm ± 1 μm 0,0001 mm
IG5003-G 3-Point MICROTEST 60–90 30 mm 110 mm ± 1.5 μm ± 1 μm 0,0001 mm
IG5004-G 3-Point MICROTEST 90–140 50 mm 140 mm ± 1.5 μm ± 1 μm 0,0001 mm
IG5005-G 3-Point MICROTEST 140–240 100 mm 210 mm ± 2 μm ± 1 μm 0,0001 mm
IG5006-G 3-Point MICROTEST 240–400 160 mm 300 mm ± 2 μm ± 1 μm 0,0001 mm
IG5021-G 3-Point MICROTEST 50–75 25 mm 110 mm ± 1.5 μm ± 1 μm 0,0001 mm
IG5022-G 3-Point MICROTEST 75–115 40 mm 140 mm ± 1.5 μm ± 1 μm 0,0001 mm
IG5023-G 3-Point MICROTEST 115–185 70 mm 210 mm ± 2 μm ± 1 μm 0,0001 mm
IG5023-G 3-Point MICROTEST 185–315 130 mm 300 mm ± 2 μm ± 1 μm 0,0001 mm
Microtest ? Digital Technology:
40
IG5001-G
IG5002-G
IG5003-G
IG5004-G
IG5005-G
IG5006-G
IG5021-G
IG5022-G
IG5023-G
IG5023-G
Standard-Edition Eco-Line
IE5001-E 3-Point MICROTEST 30–40 10 mm ± 3 μm ± 3 μm
IE5002-E 3-Point MICROTEST 40–60 20 mm ± 3 μm ± 3 μm
IE5003-E 3-Point MICROTEST 60–90 30 mm ± 3 μm ± 3 μm
IE5004-E 3-Point MICROTEST 90–140 50 mm ± 4 μm ± 3 μm
IE5005-E 3-Point MICROTEST 140–240 100 mm ± 4 μm ± 3 μm
IE5006-E 3-Point MICROTEST 240–400 160 mm ± 4 μm ± 3 μm
IE5021-E 3-Point MICROTEST 50–75 25 mm ± 3 μm ± 3 μm
IE5022-E 3-Point MICROTEST 75–115 40 mm ± 3 μm ± 3 μm
IE5023-E 3-Point MICROTEST 115–185 70 mm ± 4 μm ± 3 μm
IE5023-E 3-Point MICROTEST 185–315 130 mm ± 4 μm ± 3 μm
IE7000-E Display Eco-Line 0,001 mm
Head Only! No Display!
Gold-Edition
Art. Nr.? DeSCRJPTion ? in mm Measuring range Measuring depth Linear accuracy Repetition accuracy Read-out
I
IE5001 3-Point MICROTEST 30–40 10 mm 50 mm ± 2 μm ± 1,5 μm 0,001 mm
IE5002 3-Point MICROTEST 40–60 20 mm 110 mm ± 2 μm ± 1,5 μm 0,001 mm
IE5003 3-Point MICROTEST 60–90 30 mm 110 mm ± 2 μm ± 1,5 μm 0,001 mm
IE5004 3-Point MICROTEST 90–140 50 mm 140 mm ± 2 μm ± 1,5 μm 0,001 mm
IE5005 3-Point MICROTEST 140–240 100 mm 210 mm ± 3 μm ± 1,5 μm 0,001 mm
IE5006 3-Point MICROTEST 240–400 160 mm 300 mm ± 3 μm ± 1,5 μm 0,001 mm
IE5021 3-Point MICROTEST 50–75 25 mm 110 mm ± 2 μm ± 1,5 μm 0,001 mm
IE5022 3-Point MICROTEST 75–115 40 mm 140 mm ± 2 μm ± 1,5 μm 0,001 mm
IE5023 3-Point MICROTEST 115–185 70 mm 210 mm ± 3 μm ± 1,5 μm 0,001 mm
IE5023 3-Point MICROTEST 185–315 130 mm 300 mm ± 3 μm ± 1,5 μm 0,001 mm
M2001 3-Pt. Internal-Micrometer 30–40 10 mm 110 mm ± 2 μm ± 1,5 μm 0,001 mm
IM2002 3-Pt. Internal-Micrometer 40–60 20 mm 110 mm ± 2 μm ± 1,5 μm 0,001 mm
IM2003 3-Pt. Internal-Micrometer 60–90 30 mm 110 mm ± 2 μm ± 1,5 μm 0,001 mm
IM2004 3-Pt. Internal-Micrometer 90–140 50 mm 140 mm ± 2 μm ± 1,5 μm 0,001 mm
IM2005 3-Pt. Internal-Micrometer 140–240 100 mm 210 mm ± 3 μm ± 1,5 μm 0,001 mm
IM2006 3-Pt. Internal-Micrometer 240–400 160 mm 300 mm ± 3 μm ± 1,5 μm 0,001 mm
IM2007 3-Pt. Internal-Micrometer 400–650 250 mm 520 mm ± 5 μm ± 2,5 μm 0,001 mm
IM2008 3-Pt. Internal-Micrometer 650–900 250 mm 520 mm ± 7 μm ± 3,5 μm 0,001 mm
IM2009 3-Pt. Internal-Micrometer 900–1150 250 mm 520 mm ± 8 μm ± 4,5 μm 0,001 mm

KR0040-E ? 40
KR0060-E ? 60
KR0075-E ? 75
KR0090-E ? 90
KR0140-E ? 140
KR0185-E ? 185
KR0240-E ? 240
Standard
Art. Nr.? Value
KR0008 ? 8
KR0012 ? 12.5
KR0017 ? 17.5
KR0025 ? 25
KR0030 ? 30
KR0040 ? 40
KR0060 ? 60
KR0075 ? 75
KR0090 ? 90
KR0140 ? 140
KR0185 ? 185
KR0240 ? 240
KR0300 ? 300
KR0400 ? 400
KR0650 ? 650
KR0900 ? 900
KR0040-G ? 40
KR0060-G ? 60
KR0075-G ? 75
KR0090-G ? 90
KR0140-G ? 140
KR0185-G ? 185
KR0240-G ? 240
Master gauges
Art. Nr.? Value
KL0240 ? 40/90/240
KL
IMS001 ? 6–10 mm including: 2 Cone-Internal-Micrometer ? 6–10 mm*, 1 control ring
? 8 mm, 1 Extension 100 mm, 1 adjusting tool.
IMS002 ? 10–20 mm including: 4 Cone-Internal-Micrometer ? 10–20 mm, 2 control rings
? 12.5/17.5 mm, 1 Extension 100 mm, 1 adjusting tool.
IMS003A ? 20–90 mm including: 2 Cone-Internal-Micrometer ? 20–30 mm, 3 MICROTEST-
Internal-Micrometer ? 30–90 mm, 3 control rings ? 25/40/90 mm, 1 Extension 200
mm, 1 tool set.
IMS003B ? 30–90 mm including: 3 MICROTEST-Internal-Micrometer ? 30–90 mm, 2 con-
trol rings ? 40/90 mm, 1 Extension 200 mm, 1 screwdriver.
IMS004 ? 90–400 mm including: 3 MICROTEST-Internal-Micrometer ? 90–400 mm, 1 Master
gauge ? 40/90/240 mm, 1 Extension 200 mm, 1 screwdriver.
IMS005A ? 20–400 mm including: 2 Cone-Internal-Micrometer ? 20–30 mm, 6 MICROTEST-
Internal-Micrometer ? 30–400 mm, 1 control ring ? 25 mm, 1 Master gauge ?
40/90/240 mm, 1 Extension 200 mm, 2 screwdriver.
IMS005B ? 30–400 mm including: 6 MICROTEST-Internal-Micrometer ? 30–400 mm,
1 Master gauge ? 40/90/240 mm, 1 Extension 200 mm, 2 screwdriver.
IMS006 ? 6–400 mm including: 8 Cone-Internal-Micrometer ? 6–30 mm*, 6 MICRO TEST-
Internal-Micrometer ? 30–400 mm, 4 control rings ? 8/12.5/17.5/25 mm 1 Master
gauge ? 40/90/240 mm, 3 Extensions 100/100/200 mm, 3 screwdriver, 3 adjusting
