- ? Large size high resolution (1440*1080 pixels), high-performance OLED display.
- ? Can be customized to adjust the interpupillary distance between 56~71mm, and the observation comfort is better.
- ? Support low-light mode, infrared thermal imaging mode, and dual-light fusion mode to meet the needs of day and night observation and law enforcement.
- ? Built-in high-resolution (1920*1080 pixel) low-light camera, WIFI camera, and video function, more convenient on-site forensics and video recording.
- ? Built-in GPS positioning, precise positioning of longitude, latitude, and altitude.
- ? Built-in three-dimensional electronic compass, which can display the azimuth angle, horizontal roll, and pitch angle parameters in real-time.
- ? 1000m accurate laser ranging with independent switch laser indicator, which is more convenient for target positioning.
- ? IP66 encapsulation is suitable for various environments.
我司所有产品均含税运(13个点专票+顺丰包邮)
一. Main feature
二. Technical parameter
Items
MS715E
MS715
MS715P
Detector
VOx uncooled focal plane type
Spectral range
8 - 14 μm
Resolution
384×288
640×512
Pixel spacing
12μm
NETD
≤35mk@30℃
IR lens
Focal length
35mm
50mm
50mm
FOV
7.5°*5.7°（±5%）
5.3°*4.0°（±5%）
8.8°*7.0°（±5%）
Focusing method
Manual focus
Low-light lens
Resolution
1920（H）×1080（V）
Image display
Monitor
Binocular 0.39-inch color OLED, resolution 1440*1080
Interpupillary distance
56~71mm adjustable
Diopter adjustment
-5D~+5D adjustable
Image storage
Storage card
Built-in memory
Storage method
Photo/Video
File format
JPG/MP4
Capacity
Standard 32G
Function
Brightness/ Gainess
Auto/manual
Image correction
Auto/manual
E-zoom
1.0~8.0x
Picture-in-picture
Yes
Hotspot Tracking
Yes
Laser Ranging
/
1000m±1m
Distance display
/
Real-time display of ranging distance
Laser pointer
/
Yes
GPS positioning
/
Yes
Electronic compass
Yes
Wifi transmission
Yes
Scene mode
Natural, enhanced, highlighted
Image mode
Low light mode, infrared thermal imaging mode, dual light fusion mode
Image color code
White hot, black hot, iron red, red hot, ocean, desert, forest, etc.
Power system
Battery type
2 18650 batteries
Battery continuous working time
>5h
Charging method
Support online charging and dedicated charger
External power supply
DC5V/2A（USB Type-C）
Sleep function
Yes
Environment
Working temperature
-30℃～55℃
Storage temperature
-40℃～70℃
Humidity
≦95％（non-condensing）
Impact resistance
30g，GB/T2423.5（IEC60068-2-27）
Anti-vibration
2g，GB/T2423.10（IEC60068-2-6）
Encapsulation
IP66
Physical
Weight
≤0.6Kg（without battery）
Color
Black
Dimension
211（L）mm×145（W）mm× 74（H）mm
External interface
Data interface
Yes
External video
HDMI
USB
Yes
Installation interface
1/4"-20-UNC
Detection distance
Human（1.8×0.5）m
Low light：3200m
IR：1400m
Fusion：1400m
Low light：3200m
IR：2000m
Fusion：2000m
Low light：3200m
IR：2000m
Fusion：2000m
Vehicle（2.3×2.3）m
Low light：5100m
IR：2300m
Fusion：2300m
Low light：5100m
IR：3200m
Fusion：3200m
Low light：5100m
IR：3200m
Fusion：3200m
Detection distance
Human（1.8×0.5）m
Low light：1600m
IR：700m
Fusion：700m
Low light：1600m
IR：1000m
Fusion：1000m
Low light：1600m
IR：1000m
Fusion：1000m
Vehicle（2.3×2.3）m
Low light：2500m
IR：1100m
Fusion：1100m
Low light：2500m
IR：1600m
Fusion：1600m
Low light：2500m
IR：1600m
Fusion：1600m
